SPECIFICATIONS

Brand Name: NoEnName_Null

Origin: Mainland China

Certification: CE

Applicable Industries: Food Shop, Food & Beverage Shops, Lab

Condition: New

Place of Origin: China

Brand Name: YG

Ice Shape: dry ice

Voltage: 220

Power: 2.5

Weight: 200 KG

Warranty: 1 Year

Key Selling Points: Automatic

Ice storage capacity: Other

Machinery Test Report: Provided

Video outgoing-inspection: Provided

Warranty of core components: 1 Year

Core Components: PLC

Application: Industrial

Marketing Type: New Product 2020

1.This is a custom machine. The price on the page is only a deposit, and does not include shipping, accessories and packaging fees.

2.Please contact Amanda for a free quote❤
Whatsapp/WeChat/Phone number : +86 17838188983
Email : salesmachinery@yg797.com



Product Description

Special design concept, high mechanical manufacturing precision, equipped control system, software and advanced measurement. This series of granular dry ice machine is widely used in dry ice cleaning, low temperature preservation and cold chain transportation, smoke effect and other industries. This machine is a fully automatic production equipment. It can be started by one-button button and can control all functions, which greatly improves production efficiency and saves production costs.

Technical Parameters

Model	HR-KL-50	HR-KL-80	HR-KL-125	HR-KL-250	HR-KL-500
Production capability	40-50 kg/h	70-80kg/h	125-140 kg/h	250 kg/h	300-500 kg/h
Dry ice specification	Φ3mm,Φ15mm	Φ3mm,Φ16mm,Φ19mm	Φ3mm,Φ16mm, Φ19mm	Φ3mm,Φ16mm, Φ19mm	Φ3mm,Φ10mm, Φ16mm,Φ19mm
The density of dry ice	1550kg/m³	1550kg/m³	1550kg/m³	1550kg/m³	1550kg/m³
Liquid and solid co2 conversion ratio	≥42%	≥42%	≥42%	≥42%	≥42%
The total power	2.5kw	4kw	5.5kw	11kw	18.5kw
Equipment weight	200KG	350kg	500kg	1200kg	1.8T
Overall dimensions	90cm×50cm×90cm	135cm×65cm×125cm	130cm×65cm×155cm	150cm×90cm×170cm	160cm×135cm×175cm

Features

1. The body is made of stainless steel, and the fully enclosed design makes the equipment more integrated, reduces the noise of the equipment when it is working, and prevents the danger caused by the accidental touch of the personnel during the work. 2. The core electrical parts are original. 3. The hydraulic pump station and the pellet forming module are all built-in. On the one hand, it reduces the footprint of the equipment, and on the other hand, it also makes dry ice production avoid the influence of dust. 4. Touch LCD panel operation, you can set the number of hydraulic cylinder purge, working time, etc., reducing the error rate of manual operation. 5. Optional food-grade configuration of the hydraulic system (using stainless steel parts and edible food oil as the hydraulic transmission medium)

Company Profile

FAQ

Dry ice blast cleaning

Q1:WHAT IS DRY ICE? Dry ice is the solid state of carbon dioxide (CO2) formed at a temperature of -79 °C. Carbon dioxide is naturally found as a gas on Earth. It is non-toxic and tasteless, and often used to saturate drinks to give them a fresh taste and prolong consumption. Dry ice is also used in the food industry to cool food or applied in health services. Q2:DRY ICE CLEANING THEORY? When the dry ice cleaning machine forces tiny dry ice pellets blasted on to a surface, the unwanted contaminants freeze and fracture, then an explosion of energy takes place, resulting in the thorough removal of unwanted coating, such as grease, oil, paint, rust, adhesives, tar, ink, dirt, resins, etc. Q3: THREE TYPES OF PHYSICAL INTERACTION DURING DRY ICE BLASTING PROCESS? 1.The kinetic effect: the dry ice particles being accelerated to high speed. 2.The thermal effect: the dry ice particles hit the dirt layer at -78.5° C, cool it down abruptly, it contracts and forms cracks. Due to the different coefficients of thermal expansion, the compound between the surface and the dirt is loosened. 3.The sublimation: on impact, the carbon dioxide directly transforms from a solid to a gaseous state and expands about 700 times the volume in a split second. This expansion literally 'blasts off' the dirt from the surface. As a result, only the dissolved dirt particles remain at the end of the cleaning process and can be easily disposed of. Q4:WHY CHOOSE DRY ICE CLEANING METHOD? Dry ice blasting is a cleaning method that is effective, gentle on the cleaned materials, and environmentally friendly. The dry ice cleaning process only removes residues and no secondary waste is produced. Dry ice lets you gently and ecologically clean deposits of sediment and residue without needing to dismantle any of your equipment. Therefore, save time and considerable monetary costs. Detailed speaking, dry ice cleaning method has the below advantages: *No water is required, non-conductive, no need to dry allows for immediate use after cleaning. *No chemical is required, no secondary waste, nvironmentally responsible. *Clean in-place, no disassembly required, no need to rinse or cool, reduce production downtime and unplanned maintenance, increase production efficiencies. *Clean faster and more effectively, decrease cleaning time and labor costs. *Non-abrasive, eliminate wear and tear on machinery or parts. *It is also non-toxic, odourless, and suitable for any surfaces-metal, wood, and concrete, even on fine wood grains, glass, or textiles. *It is workable for different dirt/coating, such as grease, oil, paint, rust, adhesives, tar, ink, dirt, resins, etc. *Dry ice can inhibit the growth of bacteria. The dry ice cleaning process also stops the growth of fungi and spores and reduces the presence of other biological contaminants.
